GHR-DC  Four Pump Linear Liquid Filling ＆ Capping Machine
Description：
GHR-D four pump linear liquid filling ＆ capping machine is the new generation utility product , developed from foreign advanced technology to suit to market demand . the machine adopt vulome injection pump to fill high precision , long life , high temperature resisting and erosion resisting . the machine combine filling and capping in one boby , apply to pesticide , chemical , pharmaceutical , foodstuff , cosmetic etc. adopt SS316L injection pump to fill high precision , large range of adjusting dosage . SS316L vulome injection pump system do not absorb the medicament ,good chemical stability , beable to resist high temperature and erosion . low level liquid receiver , be convenient to clean . no bottle ,no fill ,auto count the quantity .filling system has the function of shrinking , no drop leak . apply to fill various viscosity liquid . filling needle is dving bottom of bottle to fill and moving up slowly , avoid bubbling . filling and sealing are in one body of the machine , economical and low space possessing magnetic moment capping system , adjust degree of tightness freely. The whole machine is designed according to requirement of GMP .
Penark : also applied to seal aluminum cap, theftproof cap, screw-thread cap etc.
Main technical parameters:
1、 Production capacity：2500-3000 bottles/h
2、 Bottle type: 30-1000mlplastic
3、 tolerance of filling quantity : ≤±1％standard filled quantity
4、 yield of cap–rotating : ≥99％
5、 Power supply: 380V/50HZ
6、 Power consumption : ≤1.2kw
7、 single machine noise : ≤70db
8、 Weight: approx. 600kg
9、 Dimension:2500X850X1600mm
